Please note, make and model of machine supplied may be different to the specifications below. If you require exact figures, please call our office.
| Specification | Value |
|---|---|
| Measurements | |
| Working height max. - indoor(1) | 9.96 m |
| Working height max. - outdoor(1) | 7.79 m |
| A Platform height max. - indoor | 7.96 m |
| A Platform height max. - outdoor | 5.79 m |
| B Platform height - stowed | 1.19 m |
| C Platform length - outside | 2.26 m |
| C Platform length - outside, extended | 3.18 m |
| Slide-out platform extension deck - length | 0.91 m |
| D Platform width - outside | 0.81 m |
| Guardrail height | 1.10 m |
| Toeboard height | 15 cm |
| E Height - stowed (folding rails) | 2.31 m |
| E Height - stowed (rails lowered) | 1.94 m |
| F Length machine - stowed | 2.44 m |
| F Length machine - stowed, extended | 3.33 m |
| G Width | 0.81 m |
| H Wheelbase | 1.85 m |
| I Ground clearance (center) - pothole guards retracted | 12 cm |
| I Ground clearance - pothole guards deployed | 2.30 cm |
| Productivity | |
| Maximum platform occupancy (in/out) | 2 / 1 |
| Lift capacity | 227 kg |
| Lift capacity - extension deck extended | 113 kg |
| Max. platform drive height | 7.96 m |
| Drive speed - stowed | 3.2 km/h |
| Drive speed - raised | 0.8 km/h |
| Gradeability - stowed(2) | 25% |
| Turning radius - inside/outside | 0 / 2.13 m |
| Lifting speed - raise/lower | 43 / 33 sec |
| Tilt sensor activation (front to back/side to side) | 3° / 1.5° |
| Tires - solid non-marking | 38×13 cm |
| Power | |
| Power | 24 V DC (4×6 V 225 Ah) |
| Hydraulic tank capacity (E-Drive) | 15 L |
| Hydraulic tank capacity (hydraulic drive) | 17 |
| Weight(3) and Floor Loading(4 | |
| Weight | 2,145 kg |
| Tire load max. | 826 kg |
| Tire contact pressure | 824 kPa |
| Occupied floor pressure | 12.91 kPa |
| Sound and Vibration Levels | |
| Sound Pressure level (ground workstation) | < 70 dBA |
| Sound Pressure level (platform workstation) | < 70 dBA |
| Vibrations | < 2.5 m/s2 |
